2.4 Expansion Slots (PCI Express Slots)
There are 2 PCI Express slots on this motherboard.
PCIE Slot:
PCIE1 (PCIe 2.0 x1 slot) is used for PCI Express cards with x1 lane
width cards.
PCIE2 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graph-
ics cards.
Before installing an expansion card, please make sure that the power supply
is switched off or the power cord is unplugged. Please read the documenta-
tion of the expansion card and make necessary hardware settings for the
card before you start the installation.
