English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 2 x 240-pin DDR3/DDR3L DIMM Slots (DDR3_A1, DDR3_B1)
5 ATX Power Connector (ATXPWR1)
6 USB 3.0 Header (USB3_1_2)
7 USB 2.0 Header (USB9_10)
8 Chassis Fan Connector (CHA_FAN1)
9 SATA3 Connector (SATA3_2)
10 SATA3 Connector (SATA3_3)
11 SATA3 Connector (SATA3_1)
12 SATA3 Connector (SATA3_0)
13 System Panel Header (PANEL1)
14 Power LED and Speaker Header (SPK_PLED)
15 USB 2.0 Header (USB1_2)
16 TPM Header (TPMS1)
17 Clear CMOS Jumper (CLRMOS1)
18 Chassis Intrusion Header (CI1)
19 COM Port Header (COM1)
20 Front Panel Audio Header (HD_AUDIO1)
21 Chassis Fan Connector (CHA_FAN2)
