In the OC Tweaker screen, you can set up overclocking features.
BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
Overclocking may cause
damage to your CPU and
motherboard.
It should be done at
your own risk and
expense.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
OC Tweaker Settings
Load CPU EZ OC Setting [Press Enter]
BCLK Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[133]
[100]
[Auto]
Boot Failure Guard
Spread Spectrum
[Enabled]
[Auto]
CPU Ratio Setting
QPI Frequency
DRAM Frequency
[20]
[Auto]
[Auto]
Load Memory EZ OC Setting
Load XMP Setting
Intelligent Energy Saver
Good Night LED
[Press Enter]
[Disabled]
[Disabled]
20
Auto
DDR3_1333
Profile 1 : DDR3 2000 9-9-9-27 1.65V
Load CPU EZ OC Setting
You can use this option to load CPU EZ overclocking setting. Please note
that overclocing may cause damage to your CPU and motherboard. It
should be done at your own risk and expense.
Load Memory EZ OC Setting
You can use this option to load memory EZ overclocking setting. Please
note that overclocing may cause damage to your memory and motherboard.
It should be done at your own risk and expense.
Load XMP Setting
You can use this option to load XMP memory setting. Configuration options:
[Profile 1] and [Default].
Intelligent Energy Saver
Intelligent Energy Saver is a revolutionary technology that delivers
unparalleled power savings. The default value is [Disabled]. Configuration
options: [Enabled] and [Disabled]. If you want to enable this function,
please set this item to [Enabled]. Besides the BIOS option, you can also
choose our Intelligent Energy Saver utility to enable this function.
Good Night LED
Enable this option to turn off Power LED and Lan LED when the system is
power on. The keyboard LED will also be turned off in S1, S3 and S4 state.
The default value is [Disabled].
Overclock Mode
Use this to select Overclock Mode. Configuration options: [Auto], [Manual],
[I.O.T.] and [Optimized]. The default value is [Auto]. If you select [Manual],
Untied Overclocking function is enabled. Please refer to page 37 for the
details of Untied Overclocking Technology. Therefore, you are allowed to
adjust the Host frequency and PCIE frequency in the following two items.
