ASROCK H610M-ITX/ac User Manual

139
H610M-IT X/ac
Bahasa Indonesia
Spesikasi
Platform
•
Bentuk dan Ukuran Mini-ITX
•
Desain Kapasitor Solid
CPU
•
Mendukung Prosesor Intel® Core
TM
Gen ke-12 (LGA1700)
•
Desain Digi Power
•
Desain 6 Fase Daya
•
Mendukung Teknologi Intel® Hybrid
•
Mendukung Teknologi Intel® Turbo Boost Max 3.0
Chipset
•
Intel® H610
Memori
•
Teknologi Memori DDR4 Dua Saluran
•
2 x Slot DIMM DDR4
•
Mendukung memori DDR 4 non-ECC, tanpa buer hingga 3200*
* Lihat Daar Dukungan Memori pada situs web ASRock untuk
informasi selengkapnya. (http://www.asrock.com/)
•
Mendukung modul memori ECC UDIMM (berjalan dalam mode
non-ECC)
•
Kapasitas maksimum memori sistem: 64GB
•
Mendukung Intel® Extreme Memory Prole (XMP) 2.0
Slot Ekspansi
•
1 slot PCIe Gen4x16*
* Mendukung SSD NVMe sebagai disk boot
•
1 x Soket M.2 Vertikal (Tombol E), mendukung modul jenis 2230
WiFi/WiFi BT PCIe dan Intel® CNVi (WiFi/BT terintegrasi)
Gras
* Intel® UHD Graphics Built-in Visuals dan output VGA hanya
didukung dengan prosesor yang terintegrasi GPU.
•
Arsitektur Gras Intel® X
e
(Gen 12)
•
Output gras ganda: Mendukung port HDMI dan DisplayPort 1.4
melalui pengontrol layar mandiri
•
Mendukung HDMI 2.1 TMDS Kompatibel dengan maks. resolusi
hingga 4K x 2K (4096x2160) @ 60Hz
•
Mendukung DisplayPort 1.4 dengan resolusi maks, DSC
(terkompresi) hingga 8K (7680x4320) @ 60Hz / 5K (5120x3200) @
120Hz

ASROCK H610M-ITX/ac Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel H610
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
ATX Power connector (24-pin)	Yes
Number of SATA III connectors	4
LAN controller	Intel® I219-V
Wi-Fi standards	802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	6.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	3200 MHz
Cables included	SATA
Maximum resolution	7680 x 4320 pixels
Parallel processing technology support	Not supported
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
