Page #96 background imageLoading...
Page #96 background image
92
Polski
Polski
•
Obsługa HDCP 2.3 przy zgodności z HDMI 2.1 TMDS i porty
DisplayPort 1.4
Audio
•
Dźwięk HD 7.1 CH (kodek audio Realtek ALC897)
•
Obsługa zabezpieczenia przed przepięciami
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
Giga PHY Intel® I219V
•
Obsługa Wake-On-LAN
•
Obsługa zabezpieczenia przed wyładowaniami atmosferycznymi/
ESD
•
Obsługa Energy Ecient Ethernet 802.3az
•
Obsługa UEFI PXE
Bezprzewo-
dowa sieć LAN
•
Moduł WiFi 802.11ac
•
Obsługa IEEE 802.11a/b/g/n/ac
•
Obsługa dwóch pasm (2,4/5 GHz)
•
Obsługa wysokiej szybkości połączeń bezprzewodowych do
433 Mbps
•
Obsługa Bluetooth + Wysokiej szybkości klasa II
Tylny panel
Wejścia/
Wyjścia
•
2 x porty anteny
•
1 x port myszy/klawiatury PS/2
•
1 x port HDMI
•
1 x DisplayPort 1.4
•
2 x porty USB 3.2 Gen1 (Obsługa zabezpieczenia ESD)
•
2 x porty USB 2.0 (Obsługa zabezpieczenia ESD)
•
1 x port LAN RJ-45 z LED (LED ACT/LINK i LED SPEED)
•
Gniazda audio HD: Wejście liniowe / Głośnik przedni / Mikrofon
Przechowy-
wanie
•
4 x złącza SATA3 6,0 Gb/s*
* Jeśli gniazdo M2_1 jest zajęte przez urządzenie M.2 typu SATA,
zostanie wyłączone SATA3_0.
•
1 x Ultra M.2 Socket (M2_1, Key M), z obsługą typu 2280 SATA3
6,0 Gb/s i trybów PCIe Gen3x4 (32 Gb/s)**
** Obsługa Intel® Volume Management Device (VMD)
** Obsługa SSD NVMe, jako dysków rozruchowych
** Obsługa ASRock U.2 Kit

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK H610M-ITX/ac and is the answer not in the manual?

ASROCK H610M-ITX/ac Specifications

General IconGeneral
Processor socketLGA 1700
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors1
Audio chipRealtek ALC897
Component forPC
Motherboard chipsetIntel H610
Audio output channels7.1 channels
Motherboard form factormini ITX
DisplayPort version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
ATX Power connector (24-pin)Yes
Number of SATA III connectors4
LAN controllerIntel® I219-V
Wi-Fi standards802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Ethernet interface typeGigabit Ethernet
BIOS typeUEFI AMI
ACPI version6.0
BIOS memory size128 Mbit
System Management BIOS (SMBIOS) version2.7
Memory channelsDual-channel
Memory slots typeDIMM
Supported memory typesDDR4-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds3200 MHz
Cables includedSATA
Maximum resolution7680 x 4320 pixels
Parallel processing technology supportNot supported
RAID levels0, 1, 5, 10
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, SATA III
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Width170 mm
