ASROCK H61M-VS3 User Manual

4
3 UEFI SETUP UTILITY .......................................... 44
3.1 Introduction .................................................................... 44
3.1.1 UEFI Menu Bar .................................................... 44
3.1.2 Navigation Keys ................................................... 45
3.2 Main Screen ................................................................... 45
3.3 OC Tweaker Screen ...................................................... 47
3.4 Advanced Screen ........................................................... 51
3.4.1 CPU Conguration ............................................... 52
3.4.2 North Bridge Conguration................................... 54
3.4.3 South Bridge Conguration .................................. 55
3.4.4 Storage Conguration .......................................... 56
3.4.5 Intel(R) Rapid Start Technology ........................... 57
3.4.6 Intel(R) Smart Connect Technology ..................... 58
3.4.7 ACPI Conguration............................................... 59
3.4.8 USB Conguration ............................................... 60
3.5 Tool ................................................................................ 61
3.6 Hardware Health Event Monitoring Screen ................... 63
3.7 Boot Screen ................................................................... 64
3.8 Security Screen ............................................................. 66
3.9 Exit Screen .................................................................... 67
4 Software Support ............................................... 68
4.1 Install Operating System ................................................ 68
4.2 Support CD Information ................................................. 68
4.2.1 Running Support CD ............................................ 68
4.2.2 Drivers Menu ........................................................ 68
4.2.3 Utilities Menu........................................................ 68
4.2.4 Contact Information .............................................. 68

ASROCK H61M-VS3 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Maximum Memory	16GB
Storage Interface	4 x SATA 3Gb/s
LAN	Realtek RTL8111E Gigabit LAN
Memory Standard	DDR3 1600/1333/1066
Audio	Realtek ALC662 5.1-Channel HD Audio Codec
Memory Slots	2 x DDR3
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Video Outputs	1 x D-Sub (VGA)
