13
ASRock Restart to UEFI
Windows
®
8 brings the ultimate boot up experience. The light-
ning boot up speed makes it hard to access the UEFI setup. AS-
Rock Restart to UEFI technology is designed for those requiring
frequent UEFI access. It allows users to easily enter the UEFI
automatically when turning on the PC next time. Just simply
enable this function; the PC will be assured to access the UEFI
directly in the very beginning.
ASRock Good Night LED
ASRock Good Night LED technology can offer you a better en-
vironment by extinguishing the unessential LED. By enabling
Good Night LED in BIOS, the Power / HDD / LAN LED will be
switched off when system is on. Not only this, Good night LED
will automatically switch off Power and Keyboard LED when the
system enters into Standby / Hibernation mode as well.

Table of Contents

Other manuals for ASROCK H61MV-ITX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK H61MV-ITX and is the answer not in the manual?

ASROCK H61MV-ITX Specifications

General IconGeneral
Non-ECCYes
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds1066, 1333, 1600 MHz
Supported memory module capacities8GB
Processor socketLGA 1155 (Socket H2)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 seriesi3-2xxx, i3-3xxx, i5-2xxx, i5-3xxx, i7-2xxx, i7-3xxx
Number of SATA connectors-
Number of SATA II connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cooling typePassive
CertificationFCC, CE, WHQL, ErP/EuP
Power source typeATX
Motherboard chipsetIntel® H61
Audio output channels5.1 channels
Motherboard form factormini ITX
Supported storage drive interfacesSATA II
Parallel processing technology supportNot supported
PCI Express slots version3.0
Cables includedSATA
LAN controllerRealtek RTL8111E
Ethernet interface typeGigabit Ethernet
BIOS typeUEFI AMI
ACPI version1.1
BIOS memory size32 Mbit
