ASROCK H81M-VG4 R4.0 User Manual

6
English
1.2 Specications
Platform
•
Micro ATX Form Factor
•
Solid Capacitor design
CPU
•
Supports New 4
th
and 4
th
Generation Intel® Core
TM
i7/i5/i3/
Xeon®/Pentium®/Celeron® Processors (Socket 1150)
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel® H81
Memory
•
Dual Channel DDR3/DDR3L Memory Technology
•
2 x DDR3/DDR3L DIMM Slots
•
Supports DDR3/DDR3L 1600/1333/1066 non-ECC, un-
buered memory
•
Max. capacity of system memory: 16GB (see CAUTION)
•
Supports Intel® Extreme Memory Prole (XMP) 1.3/1.2
Expansion
Slot
•
1 x PCI Express 2.0 x16 Slot (PCIE2: x16 mode)
•
1 x PCI Express 2.0 x1 Slot
Graphics
* Intel® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU integrated.
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics 4400/4600
•
Pixel Shader 5.0, DirectX 11.1
•
Max. shared memory 1024MB
* e size of maximum shared memory may vary from dierent
operating systems.
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
Audio
•
7.1 CH HD Audio (Realtek ALC887 Audio Codec)
* To congure 7.1 CH HD Audio, it is required to use an HD
front panel audio module and enable the multi-channel audio
feature through the audio driver.
•
Supports Surge Protection
•
ELNA Audio Caps

ASROCK H81M-VG4 R4.0 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H81
Socket	LGA 1150
Maximum Memory	16GB
Storage Interface	2 x SATA3 6.0 Gb/s, 2 x SATA2 3.0 Gb/s
Audio	Realtek ALC662 Audio Codec
Memory Standard	DDR3 1600/1333
Expansion Slots	1 x PCI Express 2.0 x16, 1 x PCI Express 2.0 x1
LAN	Realtek RTL8111GR
Video Outputs	1 x D-Sub (VGA)
Memory Slots	2 x DIMM
