ASROCK J3455-ITX User Manual

5
English
J4205-ITX
J3455-ITX
1.3 Motherboard Layout
PCIE1
ATXPWR1
AUDIO
CODEC
4
DDR3_A1
DDR3_B1
CPU_FAN1
COM1
1
RoHS
1
HD_AUDIO1
3
1
5
7
12
BIOS
ROM
Front USB 3.0
LAN
CLRMOS1
1
USB3_0_1
151617
1
USB_0_1
11
SATA3_1
SATA3
_A1
10
8
9
RJ-45 LAN
USB 2.0
T: USB4
B: USB5
PS2
Keyboard
PS2
Mouse
TPMS1
1
6
CMOS
Battery
HDLED RESET
PLED PWRBTN
PANEL1
1
SATA3_ 2
SATA3 _A2
1
USB6
SPK_CI1
1
HDMI1
VGA1
DVI1
USB 3.0
T: USB2
B: USB3
Top:
Central/Bass
Center:
REAR SPK
Top:
LINE IN
Center:
FRONT
Bottom:
Optical
SPDIF
Bottom:
MIC IN
2
14
13
M2

ASROCK J3455-ITX Specifications

General

Non-ECC	Yes
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM, DDR3L-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1333, 1600, 1866 MHz
Processor cores	4
Processor model	J3455
Processor socket	-
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
Number of SATA II connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
Supported storage drive interfaces	M.2
USB connector type	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	PC
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Graphics card	HD Graphics 500
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
BIOS type	UEFI AMI
Trial software	AntiVirus
Bundled software	ASRock Power Gear ASRock XFast LAN Google Chrome Browser and Toolbar
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
