1.4 I/O Panel1.4 I/O Panel
1.4 I/O Panel1.4 I/O Panel
1.4 I/O Panel
1 PS/2 Mouse Port (Green) 7 USB 2.0 Ports (USB01)
2 Parallel Port 8 USB 2.0 Ports (USB23)
3 RJ-45 Port 9 VGA Port
4 Line In (Light Blue) 10 COM Port
5 Line Out (Lime) 11 PS/2 Keyboard Port (Purple)
6 Microphone (Pink)
1
3
7
8
5
4
6
9
10
11
2
LAN Port
ACT/LINK
LED
SPEED
LED
LAN Port LED Indications
Activity/Link LED SPEED LED
Status Description Status Description
Off No Activity Green 10Mbps connection
Blinking Data Activity Green 100Mbps connection
