Chipset Configuration:
AGP Mode: This feature will be set to [Auto] as default.
AGP Aperture Size: It refers to a section of the PCI memory address range
used for graphics memory. It is recommended to leave this field at the
default value unless the installed AGP card’s specifications requires other
sizes.
AGP Fast Write: This allows you to enable or disable the feature of AGP fast
write protocol support.
OnBoard VGA Share Memory: This allows you to select the size of share
memory for onboard VGA. Onboard VGA will get better resolution if larger
size of share memory is selected. Please do not select [None] if AGP or PCI
graphics card is not inserted.
PCI Delay Transaction: Enable PCI Delay Transaction feature will free the PCI
Bus when the CPU is accessing 8-bit ISA cards. Disable this feature when
using ISA cards that are not PCI 2.1 compliant.
USB Controller: Use this to enable or disable the use of USB controller.
USB Device Legacy Support: Use this to enable or disable the support to
emulate legacy I/O devices such as mouse, keyboard,... etc.
DRAM CAS# Latency:
This is used to adjust the means of memory accessing. Configuration options:
[Auto],[3.0],[2.5], [2]. The default value is [Auto].
Over Vcore Voltage: This Feature allows you to increase the CPU Vcore
Voltage with tow levels. The default value is [Disabled].
VCCM Voltage: This Feature allows you to adjust Memory interface Voltage
The default value is [High].
V-Link Speed: This Feature allows you to speed up the V-Link speed.
The default value is [Normal].
AMIBIOS SETUP UTILITY - VERSION 3.31a
