BIOS SETUP UTILITY
Main Smart
H/W Monitor Boot Security Exit
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Advanced
Advanced Settings
WARNING : Setting wrong values in below sections
may cause system to malfunction.
CPU Configuration
Memory Configuration
ACPI Configuration
Chipset Configuration
Storage Configuration
PCIPnP Configuration
Floppy Configuration
SuperIO Configuration
USB Configuration
Options for CPU
3.43.4
3.43.4
3.4
Advanced ScreenAdvanced Screen
Advanced ScreenAdvanced Screen
Advanced Screen
In this section, you may set the configurations for the following items: CPU
Configuration, Memory Configuration, Chipset Configuration, ACPI Configuration,
Storage Configuration, PCIPnP Configuration, Floppy Configuration, SuperIO
Configuration, and USB Configuration.
Setting wrong values in this section may cause
the system to malfunction.
BIOS SETUP UTILITY
CPU Configuration
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
Spread Spectrum
Enhanced Halt State
L3 Cache Allocation
Advanced Clock Calibration
Boot Failure Guard
Cool'n'Quiet
Secure Virtual Machine
Processor Maximum Frequency
North Bridge
Processor Maximum Voltage
Maximum Frequency
HT Bus Speed
HT Bus Width
[Auto]
[Auto]
x10.5 2100 MHZ
x9.0 18
1.2500 V
00 MHz
[Auto]
[Enabled]
[Auto]
[Enabled]
[Disabled]
[Auto]
[Disabled]
Multiplier/Voltage Change
[Auto]
Select the over clock
mode.
3.4.13.4.1
3.4.13.4.1
3.4.1
CPU ConfigurationCPU Configuration
CPU ConfigurationCPU Configuration
CPU Configuration
preparing an additional floppy diskette or other complicated flash utility.
Please be noted that the USB flash drive or hard drive must use FAT32/16/
12 file system. If you execute ASRock Instant Flash utility, the utility will
show the BIOS files and their respective information. Select the proper
BIOS file to update your BIOS, and reboot your system after BIOS update
process completes.
