ASROCK P43DE3 - Page 39

3838
3838
38
BIOS SETUP UTILITY
Standard Memory Settings
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
XMP Technology
[Auto]
DRAM tCL
DRAM tRCD
DRAM tRP
DRAM tRAS
DRAM tRFC
DRAM tWR
DRAM tWTR
DRAM tRRD
DRAM tRTP
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
Profile 1 : DDR3 2000 7-8-7-20 1.65V
Standard Memory Settings : 7-8-7-20-78-10-8-7-8
Auto
Profile 1
Options
XMP Technology
Use this option to adjust XMP memory. Configuration options: [Auto] and
[Profile 1]. The default value is [Auto].
DRAM tCL
This controls the number of DRAM clocks for TCL. Min: 5. Max: 10. The
default value is [Auto].
DRAM tRCD
This controls the number of DRAM clocks for TRCD. Min: 3. Max: 10. The
default value is [Auto].
DRAM tRP
This controls the number of DRAM clocks for TRP. Min: 3. Max: 10. The
default value is [Auto].
DRAM tRAS
This controls the number of DRAM clocks for TRAS. Min: 9. Max: 28. The
default value is [Auto].
DRAM tRFC
This controls the number of DRAM clocks for TRFC. Min: 15. Max: 78. The
default value is [Auto].
DRAM tWR
This controls the number of DRAM clocks for TWR. Min: 3. Max: 15. The
default value is [Auto].
DRAM tWTR
This controls the number of DRAM clocks for TWTR. Min: 2. Max: 15. The
default value is [Auto].
DRAM tRRD
This controls the number of DRAM clocks for TRRD. Min: 2. Max: 15. The
default value is [Auto].
DRAM Timing Configuation
