ASROCK P43DE3 - Page 41

4040
4040
40
BIOS SETUP UTILITY
DRAM RCOMP Settings
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
DRAM CH0 RCOMP ODT
Value
Min=1
Max-63
DRAM CH0 RCOMP ODT
[Auto]
DRAM CH0 G0 (Data)
DRAM CH0 G1 (Command)
DRAM CH0 G2 (Control1)
DRAM CH0 G3 (Control2)
DRAM CH0 G4 (Clocks1)
DRAM CH0 G5 (Clocks2)
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
DRAM CH0 RCOMP Settings : 54-0-11-6-6-6-6
DRAM CH1 RCOMP ODT
DRAM CH1 G0 (Data)
DRAM CH1 G1 (Command)
DRAM CH1 G2 (Control1)
DRAM CH1 G3 (Control2)
DRAM CH1 G4 (Clocks1)
DRAM CH1 G5 (Clocks2)
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
DRAM CH1 RCOMP Settings : 54-0-8-8-0-8-0
DRAM RCOMP and tRD Configuration
DRAM CH0 RCOMP ODT
This controls the number of DRAM CH0 RCOMP ODT. Min: 1. Max: 63. The
default value is [Auto].
DRAM CH0 G0 (Data)
This controls the number of DRAM CH0 G0 (Data). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G1 (Command)
This controls the number of DRAM CH0 G1 (Command). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G2 (Control1)
This controls the number of DRAM CH0 G2 (Control1). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G3 (Control2)
This controls the number of DRAM CH0 G3 (Control2). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G4 (Clocks1)
This controls the number of DRAM CH0 G4 (Clocks1). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G5 (Clocks2)
This controls the number of DRAM CH0 G5 (Clocks2). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH1 RCOMP ODT
This controls the number of DRAM CH1 RCOMP ODT. Min: 1. Max: 63. The
default value is [Auto].
DRAM CH1 G0 (Data)
This controls the number of DRAM CH1 G0 (Data). Min: 1. Max: 15. The
default value is [Auto].
