BIOS SETUP UTILITY
DRAM DLL SKEW Settings
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
DRAM CH0 CLKSET0 SKEW
[Auto]
DRAM CH0 CLKSET0 SKEW Info:8-2-0-0-0-734
DRAM CH0 CLKSET1 SKEW
[Auto]
DRAM CH0 CLKSET1 SKEW Info:9-5-0-0-0-856
DRAM CH0 CMD SKEW
[Auto]
DRAM CH0 CMD SKEW Info :6-1-0-0-0-545
DRAM CH0 CTRL0 SKEW
[Auto]
DRAM CH0 CTRL0 SKEW Info :8-4-0-0-0-756
DRAM CH0 CTRL1 SKEW
[Auto]
DRAM CH0 CTRL1 SKEW Info :8-4-0-0-0-756
DRAM CH0 CTRL2 SKEW
[Auto]
DRAM CH0 CTRL2 SKEW Info :10-0-0-0-0-890
DRAM CH0 CTRL3 SKEW
[Auto]
DRAM CH0 CTRL3 SKEW Info :10-0-0-0-0-890
DRAM CH1 CLKSET0 SKEW Info :0-0-0-0-0-0
DRAM DLL SKEW Settings
DRAM CH0 CLKSET0 SKEW
This controls the number of DRAM CH0 CLKSET0 SKEW. Configuration
options: [Auto], [8] to [827]. The default value is [Auto].
DRAM CH0 CLKSET1 SKEW
This controls the number of DRAM CH0 CLKSET1 SKEW. Configuration
options: [Auto], [8] to [827]. The default value is [Auto].
DRAM CH0 CMD SKEW
This controls the number of DRAM CH0 CMD SKEW. Configuration options:
[Auto], [8] to [827]. The default value is [Auto].
DRAM CH0 CTRL0 SKEW
This controls the number of DRAM CH0 CTRL0 SKEW. Configuration options:
[Auto], [8] to [827]. The default value is [Auto].
DRAM CH0 CTRL1 SKEW
This controls the number of DRAM CH0 CTRL1 SKEW. Configuration options:
[Auto], [8] to [827]. The default value is [Auto].
DRAM CH0 CTRL2 SKEW
This controls the number of DRAM CH0 CTRL2 SKEW. Configuration options:
[Auto], [8] to [827]. The default value is [Auto].
DRAM CH0 CTRL3 SKEW
This controls the number of DRAM CH0 CTRL3 SKEW. Configuration options:
[Auto], [8] to [827]. The default value is [Auto].
DRAM CH1 CLKSET0 SKEW
This controls the number of DRAM CH1 CLKSET0 SKEW. Configuration
options: [Auto], [8] to [827]. The default value is [Auto].
DRAM CH1 CLKSET1 SKEW
This controls the number of DRAM CH1 CLKSET1 SKEW. Configuration
options: [Auto], [8] to [827]. The default value is [Auto].
