BIOS SETUP UTILITY
Voltage Settings
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
CPU Voltage
[Auto]
DRAM Voltage
GTLRef Voltage
NB Voltage
NB GTL Ref. Voltage
SB Core Voltage
SB 1.1V Voltage
VTT Voltage
PLL Voltage
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
Auto
Manual
Overdrive Offset
Options
Voltage Settings
CPU Voltage
Use this to select CPU Voltage. Configuration options: [Auto], [Manual] and
[Overdrive Offset]. The default value is [Auto].
DRAM Voltage
Use this to select DRAM Voltage. Configuration options: [Auto], [1.561V] to
[2.429V]. The default value is [Auto].
GLTRef Voltage
Use this to select GLTRef Voltage. Configuration options: [Auto],
[0.67 x Vtt], [0.65 x Vtt], [0.63 x Vtt] and [0.615 x Vtt]. The default value of
this feature is [Auto].
NB Voltage
Use this to select NB Voltage. Configuration options: [Auto], [1.15V] to
[1.55V]. The default value is [Auto].
NB GTL Ref. Voltage
Use this to select NB GTL Ref. Voltage. Configuration options: [Auto], [Normal]
and [Low]. The default value is [Auto].
SB Core Voltage
Use this to select SB core Voltage. Configuration options: [Auto], [Low],
[Middle], [High] and [Highest]. The default value is [Auto].
SB 1.1V Voltage
Use this to select SB 1.1V Voltage. Configuration options: [Auto], [1.11V] to
[1.51V]. The default value is [Auto].
VTT Voltage
Use this to select VTT Voltage. Configuration options: [Auto], [1.21V] to
[1.51V]. The default value is [Auto].
PLL Voltage
Use this to select PLL Voltage. Configuration options: [Auto], [1.50V] to
[2.50V]. The default value is [Auto].
