ASROCK PHANTOM GAMING A620I LIGHTNING WiFi User Manual

6
1.3 Motherboard Layout
BIOS
ROM
ATXPWR1
DDR5_B1 (64 bit, 288-pin module)
DDR5_A1 (64 bit, 288-pin module)
AMD
A620
PCIE1
ATX 12V1
SATA3 _2
SATA3 _1
1
USB3 2_ 4_5
HDL ED RESE T
PLE D PWRBT N
PANEL1
1
1
USB32_TC2
USB_5_6
CLRCMOS1
1
M2_1
CHA _FAN1/ WP
1
SPE AKER1
1
HD_ AUDIO 1
CPU_FAN1/WP
CPU_FAN2/WP
ADDR_LED2
1
ADDR_LED1
1
AUDIO
CODEC
USB 3.2 Gen2
T: USB32_1
B: USB32_TC1
Top:
LAN
USB 3.2 Gen1
T: USB32_3
USB 3.2 Gen2
B: USB32_2
HDMI1
USB 2.0:
USB_12
M2_WIFI_1
1
2
3
6
4
5
7
8
9
10
11
12
13
14
1517 16
Top:
LINE IN
Cent er :
FRONT
Bott om :
MIC IN
BIOS
_FB1
Top Side View

ASROCK PHANTOM GAMING A620I LIGHTNING WiFi Specifications

General

Form Factor	Mini-ITX
Chipset	AMD A620
Socket	AM5
Memory Slots	2 x DIMM
Maximum Memory	64GB
PCIe Slots	1 x PCIe 4.0 x16
Bluetooth	Bluetooth 5.2
Audio	7.1 CH HD Audio (Realtek ALC897 Audio Codec)
Memory Support	DDR5
Storage Interface	4 x SATA3
USB Ports	2 x USB 2.0
Networking	Wi-Fi 6E, 2.5G LAN
Video Outputs	1 x HDMI, 1 x DisplayPort
