ASROCK Super Alloy B150M COMBO-G User Manual

46
English
tZQCS
Congure tZQCS.
Advanced Setting
ODT WR (CH A)
Congure the memory on die termination resistors' WR for channel A.
ODT WR (CH B)
Congure the memory on die termination resistors' WR for channel B.
ODT PARK (CH A)
Congure the memory on die termination resistors' PARK for channel A.
ODT PARK (CH B)
Congure the memory on die termination resistors' PARK for channel B.
ODT NOM (CH A)
Use this to change ODT (CH A) Auto/Manual settings. e default is [Auto].
ODT NOM (CH B)
Use this to change ODT (CH B) Auto/Manual settings. e default is [Auto].
MRC Fast Boot
Enable Memory Fast Boot to skip DRAM memory training for booting faster.
Voltage Conguration
CPU Vcore Voltage
Congure the voltage for the CPU Vcore.
DRAM Voltage
Use this to congure DRAM Voltage. e default value is [Auto].
PCH +1.0 Voltage
Congure the chipset voltage (1.0V).
GT Voltage
Congure the voltage for the GT.
VCCSA Voltage
Congure the voltage for the VCCSA.

ASROCK Super Alloy B150M COMBO-G Specifications

General

Chipset	Intel B150
Form Factor	Micro ATX
PCI Express 3.0 x16	1
SATA 6Gb/s	6
LAN	Gigabit LAN
CPU Socket Type	LGA 1151
Audio Codec	Realtek ALC887
LAN Chipset	Realtek RTL8111GR
RAID Support	RAID 0, 1, 5, 10
USB 3.0 Ports	6
Audio	7.1 CH HD Audio
Video Ports	D-Sub, DVI-D, HDMI
USB Ports	6 x USB 3.0, 6 x USB 2.0
Memory Slots	4 x DDR3/DDR4 DIMM
Expansion Slots	1 x PCI Express 3.0 x16 Slot, 2 x PCI Express 3.0 x1 Slots
