X300-ITX / X300-ITX/COM
23
English
2.4 Expansion Slot (PCIe Slot)
ere are 1 PCIe slot on the motherboard.
PCIe slot:
PCIE2 (PCIe 3.0 x16 slot) is used for PCIe x16 lane width graphics cards.
PCIe Slot Conguration
PCIE2
Ryzen series CPUs
(Vermeer, Matisse, Pinnacle Ridge)
Gen3x16
Ryzen series APUs
(Cezanne, Renoir)
Gen3x16
Ryzen series APUs
(Picasso, Raven Ridge)
Gen3x8
Athlon series CPU Gen3x4
Before installing an expansion card, please make sure that the power supply is switched o
or the power cord is unplugged. Please read the documentation of the expansion card and
make necessary hardware settings for the card before you start the installation.
