ASROCK X99E-ITX/ac User Manual

56
English
tWRDR
Congure Write to Read dierent rank dead cycle Back to back READ to WRITE
from dierent rank separation parameter.
tWWDD
Congure Write to Write dierent DIMM dead cycle Back to back READ to
WRITE from dierent DIMM separation parameter.
tWWDR
Congure Write to Write dierent rank dead cycle Back to back READ to WRITE
from dierent rank separation parameter.
tRRDD
Congure Read to Read dierent DIMM dead cycle Back to back READ to WRITE
from dierent DIMM separation parameter.
tRRDR
Congure Read to Read dierent rank dead cycle Back to back READ to WRITE from
dierent DIMM separation parameter.
Advanced Setting
ODT WR (CH A)
Congure the memory on die termination resistors' WR for channel A.
ODT PARK (CH A)
Congure the memory on die termination resistors' PARK for channel A.
ODT NOM (CH A)
Use this to change ODT (CH A) Auto/Manual settings. e default is [Auto].
ODT WR (CH B)
Congure the memory on die termination resistors' WR for channel B.
ODT PARK (CH B)
Congure the memory on die termination resistors' PARK for channel B.
ODT NOM (CH B)
Use this to change ODT (CH B) Auto/Manual settings. e default is [Auto].
ODT WR (CH C)
Congure the memory on die termination resistors' WR for channel C.
