ASROCK Z370M-ITX/ac User Manual

64
65
Español
1.2 Especicaciones
Plataforma
•
Factor de forma Mini-ITX
CPU
•
Compatible con la 8
a
generación de procesadores Intel® Core
TM
(Socket 1151)
•
Digi Power design
•
Diseño de 6 fases de alimentación
•
Admite la tecnología Intel® Turbo Boost 2.0
•
Compatible con CPU serie K desbloqueada de Intel®
•
Compatible con overclocking de rango completo BCLK de
ASRock
Conjunto de
chips
•
Intel® Z370
Memoria
•
Tecnología de memoria DDR4 de doble canal
•
2 x ranuras DIMM DDR4
•
Admite memoria sin búfer DDR4 4000+(OC)*/3866(OC)/
3800(OC)/3733(OC)/3600(OC)/3200(OC)/2933(OC)/2800(OC)/
2666/2400/2133 no ECC
* Para obtener más información, consulte la lista de memorias
compatibles en el sitio web de ASRock. (http://www.asrock.com/)
* CPU Intel® de 8
a
generación compatible con DDR4 de hasta 2666.
•
Admite módulos de memoria UDIMM ECC (funcionamiento en
modo no ECC)
•
Capacidad máxima de memoria del sistema: 32 GB
•
Admite Perl de memoria extremo de Intel® (XMP) 2.0
•
Contacto 15μ Gold en ranuras DIMM
Ranura de
expansión
•
1 x ranura PCI Express 3.0 x16 (PCIE1:modo x16)
* Admite unidad de estado sólido de NVMe como disco de arranque
•
1 x Zócalo M.2 vertical (clave E) con el módulo WiFi-802.11ac
integrado (en la E/S trasera)

ASROCK Z370M-ITX/ac Specifications

General

ECC	No
Memory channels	Dual-channel
Memory slots type	DIMM
Unbuffered memory	Yes
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 4000 MHz
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® Z370
PC health monitoring	CPU, FAN, Power supply, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Maximum resolution	4096 x 2304 pixels
Parallel processing technology support	Not supported
Number of SATA connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
BIOS type	UEFI
ACPI version	6.0
BIOS memory size	16 Mbit
System Management BIOS (SMBIOS) version	2.7
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel I211-AT, Intel I219V
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	- mm
Width	170 mm
