1.2 Specications
Platform
•
Mini-ITX Form Factor
CPU
•
Supports 8
th
Generation Intel® Core
TM
Processors (Socket
1151)
•
Digi Power design
•
6 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
•
Supports Intel® K-Series unlocked CPUs
•
Supports ASRock BCLK Full-range Overclocking
Chipset
•
Intel
®
Z370
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
Supports DDR4 4000+(OC)*/3866(OC)/3800(OC)/
3733(OC)/3600(OC)/3200(OC)/2933(OC)/2800(OC)/
2666/2400/2133 non-ECC, un-buered memory
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
* 8
th
Gen Intel® CPU supports DDR4 up to 2666.
•
Supports ECC UDIMM memory modules (operate in non-
ECC mode)
•
Max. capacity of system memory: 32GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
* Supports NVMe SSD as boot disks
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ac module (on the rear I/O)
