69
English
Z690M PG Riptide/D5
ODT NOM Rd (B2)
Congure the memory on die termination resistors' NOM Rd for channel B2.
ODT NOM Wr (A1)
Congure the memory on die termination resistors' NOM Wr for channel A1.
ODT NOM Wr (A2)
Congure the memory on die termination resistors' NOM Wr for channel A2.
ODT NOM Wr (B1)
Congure the memory on die termination resistors' NOM Wr for channel B1.
ODT NOM Wr (B2)
Congure the memory on die termination resistors' NOM Wr for channel B2.
ODT PARK (A1)
Congure the memory on die termination resistors' PARK for channel A1.
ODT PARK (A2)
Congure the memory on die termination resistors' PARK for channel A2.
ODT PARK (B1)
Congure the memory on die termination resistors' PARK for channel B1.
ODT PARK (B2)
Congure the memory on die termination resistors' PARK for channel B2.
ODT PARK DQS (A1)
Congure the memory on die termination resistors' PARK DQS for channel A1.
ODT PARK DQS (A2)
Congure the memory on die termination resistors' PARK DQS for channel A2.
ODT PARK DQS (B1)
Congure the memory on die termination resistors' PARK DQS for channel B1.
ODT PARK DQS (B2)
Congure the memory on die termination resistors' PARK DQS for channel B2.
