Assa Abloy EL650 - Connection Cable Diagrams EL650, EL651; Cable EA203 Connections; Cable EA204 Connections

18
CONNECTION CABLES EL650, EL651
ÑÎÅÄÈÍÈÒÅËÜÍÛÅ ÊÀÁÅËÈ EL650, EL651
CABLE / ÊÀÁÅËÜ EA203 - EL650, EL651 <=> EL412, EL480, EL482
CABLE / ÊÀÁÅËÜ EA204 - EL650, EL651 <=> 8329
CABLE / ÊÀÁÅËÜ EA203 - EL651, EL651 <=> EL412, EL480, EL482
CABLE / ÊÀÁÅËÜ EA204 - EL651,EL651 <=> 8329
Connections between EL650 / EL651 and EL412 /
EL480 / EL482
Ïîäêëþ÷åíèÿ ìåæäó EL650 / EL651 è EL480 / EL482 / EL412
EL650, EL651
EA203
EL412, EL480, EL482
WHITE / ÁÅËÛÉ
GREEN / ÇÅ˨ÍÛÉ
BLUE / ÑÈÍÈÉ
YELLOW / ƨËÒÛÉ
BLACK / רÐÍÛÉ
RED / ÊÐÀÑÍÛÉ
Red connector / Êðàñíûé ðàçú¸ì
BLACK /
GREEN / ÇÅ˨ÍÛÉ
BLUE / ÑÈÍÈÉ
YELLOW / ƨËÒÛÉ
RED / ÊÐÀÑÍÛÉ
Connections between EL650 / EL651 and 8329
Ïîäêëþ÷åíèÿ ìåæäó EL650 / EL651 è 8329
EL650, EL651
EA204
8329
WHITE / ÁÅËÛÉ
GREEN / ÇÅ˨ÍÛÉ
BLUE / ÑÈÍÈÉ
YELLOW / ƨËÒÛÉ
BLACK / רÐÍÛÉ
RED / ÊÐÀÑÍÛÉ
WHITE / ÁÅËÛÉ
GREEN / ÇÅ˨ÍÛÉ
BLUE / ÑÈÍÈÉ
YELLOW / ƨËÒÛÉ
BLACK / רÐÍÛÉ
RED / ÊÐÀÑÍÛÉ
Red connector / Êðàñíûé ðàçú¸ì
