Assa Abloy EMTEK LISCIO - Install Inside Chassis

6
Install Inside Chassis
Cam link must remain
in the correct position
during installation.
!
Conrm the position of Cam Link.
For Left Hand Locks:
Turn to left position.
For Right Hand Locks:
Turn to right position.
Feed the Wire Harness through Inside Chassis.
4
STEP 1
STEP 2
