FIRE DOOR INSTALLATION
Before fitting the ES8100 : V-lock to a fire / smoke resistant door, the fire certification
should be examined to ensure the suitability of the electrically operated lock for that
particular door assembly.
United Kingdom (UK) and Europe (CE) Customers:
This product is only fire rated when used in Power to Open (PtO) configuration. When
this lock is fitted to fire doors, it must be protected by intumescent material as follows:
Mono Ammonium Phosphate (MAP) 1 to 2mm behind strike / lock coverplate
and 1 to 2mm around the case behind the faceplate of as shown in the fire door
manufacturer’s instructions.
Please refer to the Declaration of Performance (DoP) as found on
www.assaabloy.com/au/en/solutions/products/electromechanical-locking/es8100-v-lock
for further details incl. single wood and metal sheet, fire / smoke test report references.
Australasian Customers:
This product is only fire rated when used in Power to Lock (PtL) configuration as a
secondary lock. For Australian fire door applications, this electric lock has been
successfully fire rated up to 4 hours on fire door assemblies.
Contact the supplier for further details, such as door type and door thickness etc. that
may affect the fire door suitability and rating. Certificates can be downloaded from
www.assaabloy.com/au/en/about-us/product-certification, if the certificate is not listed,
please contact the supplier for further details.
LOCK SPECIFICATIONS
Power supply 11 - 26VDC
NO / NC contacts (50mA @ 30VDC)
NC (50mA @ 30VDC)
Unlocking : 100kg (3 wire mode), 15kg (2 wire mode)
Locking : 20kg (12W), 35kg (24W)
-10 to 55ºC
750g
256 x 30 x 42mm
IP53
Operating current
Lock Status Monitor
Door Position Monitor
Maximum door side load
Operating temp.
Mass
Dimensions
IP rating
Peak : 1000mA @ 12VDC Standby : 35mA @12VDC with LED activated
