6000 Series Grade 1 Exit Devices
8
6170(F) Surface Vertical Rod
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Item Part No. Description
35
Bottom Bolt Case
60-7010-0054-000 6170
60-7010-0053-000 6170F
36 60-7010-X052-FIN Top Rod
37 60-7010-0020-FIN Bottom Rod Assembly
38
81-9500-1514-FIN Rod Guide Packet
Consists of the following:
60-7010-9050-999 Guide, Rod (1)
60-7010-X051-FIN Cover, Rod Guide (1)
81-3110-0412-058 Screw, #8 x 1/2 RPHMS (2)
81-3115-0308-FIN Screw, Rod Guide Cover
81-0011-0404-FIN Screw, #8-32 x 1/4 FPHMS (2)
Item Part No. Description
1
Latch Assembly
60-6010-0360-048 LH
60-6010-0365-048 RH
6170, 6170F
2
Cover
60-6000-X014-FIN 6170
Not Available
6170F
3 03-0080-5047-FIN
Sex Nut Pack (4)
(Fire Rated Only)
4 60-1510-0281-FIN
Rod Extension Assy., 24"
(-10 Device Only)
5 60-1510-0278-FIN
Rod Extension Assy., 12"
(-10 Device Only)
23 81-9500-1549-FIN
Screw Packet, Cover
#8-32 x 5/16”
UFPHMS (5)
32 60-7010-X040-FIN
Cover, Top & Bottom
Latches (2)
33
Top Latch
60-7010-0049-999 6170
60-7010-0050-999 6170F
34
81-9500-1610-000 SVR Pack
Consists of the following:
60-7110-1005-048 Top Mtg. Plate
60-7010-1039-048 Bottom Mtg. Plate
60-7010-1067-048 Top Rod Connector
99-9999-4308-999 Rod Connecting Pin (2)
60-7000-1150-999 Drill Jig
60-7010-1070-018 Floor Bolt
60-7010-1055-200 Strike
81-9500-1546-000 Latch Mounting Screw Pack
81-9500-1576-000 726 Top Strike Packet
