FEATURES
CHASSIS FEATURES:
• Solid Axle Front Suspension
• StealthX transmission
• Aluminum steering plates
• 5mm Heavy Duty FT High Clearance
Links
• Integrated servo winch mount
• Adjustable bumper mounts
• Sealed Receiver Box
• Adjustable / injection molded rock
sliders
• Threaded aluminum shock bodies
• CMS [Chassis Mounted Servo]
• Universal front drive axles
• Stamped steel frame rails
• 12mm steel wheel hexes
• GKS Shock Mounts with Adjustable
Shock Location Inserts
• GKS Panhard Mount
• Aluminum Motor Plate
• Optimized ball cups for more fl uid axle
articulation
• Telescopic driveshaft’s front and rear
• Extruded aluminum driveshaft splines
• One-piece rear axle design
• Machined input pinion gear
• Metal ring gear
• Machined steel top shaft
• Metal ball bearings included
• Steel 25T servo horn
INTRODUCTION
Thank you for purchasing this Element RC product. This assembly manual contains instructions and tips for building and maintaining
your new Enduro chassis. Please take a moment to read through this manual to help familiarize yourself with these steps. We are
continually changing and improving our designs; therefore, actual parts may appear slightly different than in the illustrations. New parts
will be noted on supplementary sheets located in the appropriate parts bags.
ENDURO BUILDERS KIT 2
Always forward, never back. Here at Element RC we are always improving things, and this kit is no different. With added features
and updated materials, the updated Enduro Builder’s Kit 2 is the perfect platform for any build.
We’ve updated the Builder’s Kit 2 by including our GKS™ shock towers in front and rear. Our shock mount inserts provide the
ability to adjust shock angle, droop, and vehicle ride height without affecting spring preload. Matched up with the shock mount
inserts are our race-proven ultra-smooth Factory Team bronze shocks with black caps and collars–perfect for traversing rough
terrain. Along with the updated shock towers, we’ve included the GKS aluminum track bar mount that is bolted directly to the
frame rails. This makes the front suspension more rigid and fl ex-free with a more precise steering feel. Also included are updated
Factory Team 12.3-inch wheelbase high-clearance links with black nitrate fi nish and low-friction Delrin® pivot balls which are also
more resistant to abrasion and friction wear.
You get all these new features along with our revolutionary Stealth® X transmission with the ability to adjust the front and rear
drive ratios independently across three different levels. In the box you get both the 5.7% and 11.83% overdrive gears, and available
separately is a one-to-one ratio option for those who wish to drive the front and rear equally.
The behind-the-axle (BTA) steering greatly improves approach angle and front end clearance, making rough terrain much easier to
handle.
With all these updated features packed in one box, we know the new and improved Enduro Builder’s Kit 2 is better than ever. It’s
the perfect rig for whatever adventures lie around the next corner. Your journey begins here!
Associated Electrics, Inc.
21062 Bake Parkway.
Lake Forest, CA 92630
Customer Service
Tel: 949.544.7500
Fax: 949.544.7501
Follow Us On Social Media
www.ElementRC.com
ElementRC @Element_RC
ITEMS NEEDED
OTHER HELPFUL ITEMS
The following items aren’t required, but will
aid in the building and maintaining of your
Enduro Trail Truck.
• Threadlock (#1596)
• Green Slime (#1105)
The following items are required to build
or maintain your Enduro Trail Truck.
• 1.5mm Allen Wrench (#1500)
• 2mm Allen Wrench (#1501)
• 2.5mm Allen Wrench (#1503)
• Pliers
• Long Nose Pliers
• 5.5mm Nut Driver (#1507)
• 7mm Nut Driver (#1508)
