Associated Electrics Element RC Enduro Builder's Kit 2 - Front Suspension Build

FRONT SUSPENSION BUILD
GATE 04
08
x1
NOTE: Make sure the gear mesh
between the spur gear and pinion
has a slight amount of movement
between the two gears.
x1
x2
x1
42023
Stealth X Gearbox
Gear Cover
31530
3x5mm
BHCS
1336
Pinion Gear
18T
25225
3x3mm
Set Screw
FRONT AXLE BUILD: BAG 5
GATE 01
FRONT AXLE BUILD: BAG 5
GATE 02
x1
x1
x2
x1
x1
x1
x1
x1
x1
x2
x1
x1
x1
x2
x2
x4
x1
25187
3x14mm
BHCS
71032
2.5x14mm
SHCS
42067
Universal
42062
Steering
Block
42060
Axle Housing
Differential Cover
91474
7x14x3.5mm
Bearing
91560
5x10x4mm
Bearing
41086
2.5x16mm
SHCS
42062
Caster Block,
Left
91563
10x15x4mm
Bearing
42060
Lower 4-Link
Mount
42070
3x4x10mm
Shoulder Screw
91560
5x10x4mm
Bearing
42065
Ring Gear,
30T
42066
Pinion Gear,
8T
42061
Axle Housing,
Front
91560
5x10x4mm
Bearing
NOTE: Install Left and
right side caster blocks
and bearings
NOTE: Install left
and right side steering
blocks and universals
NOTE: Install left and
right side axle mounts
and shoulder screws
NOTE: Align the two
arrows when installing
the caster block!
BLACK GREASE
#6588
x2
x2
89208
3x14mm
FHCS
25201
3x8mm
FHCS
