Associated Electrics Element RC Enduro Builder's Kit 2 - Page 9

09
33.656906, -117.700602
FRONT AXLE BUILD: BAG 5 REAR AXLE BUILD: BAG 6
GATE 03 GATE 01
REAR AXLE BUILD: BAG 6
GATE 02
LINKS BUILD: BAG 7
GATE 01
x4
x2
41086
2.5x16mm,
SHCS
91560
5x10x4mm
Bearing
NOTE: Install left and
right side drive shafts
NOTE: Install left and right side
axle mounts and wheel hexes
x1
x1
x1
x2
x1
91474
7x14x3.5mm
Bearing
42065
Ring Gear,
30T
42066
Pinion Gear,
8T
42061
Axle Housing,
Rear
42060
Axle Housing,
Differential Cover
BLACK GREASE
#6588
112.50mm
x1
x1
25187
3x14mm
BHCS
89203
3x16mm
BHCS
x1
25187
3x14mm
BHCS
BLACK GREASE
#6588
BLACK GREASE
#6588
x2
42041
Pivot Ball,
6mm
x2
x1
42040
Rod End,
Curved
42183
FT Link,
83mm
x1
x1
91560
5x10x4mm
Bearing
42068
Drive Shaft,
Rear
x2
41089
3x6mm
LP SHCS
x1
x1
x4
x1
x1
42076
FT Wheel Hex,
6mm, Steel
42019
Wheel Hex
Pin, 2x11mm
25211
3x10mm
BHCS
42064
Steering Plate,
Right
42064
Steering Plate,
Left
NOTE: Install left and
right side wheel hexes
x1
x1
25225
Set Screw,
3x3mm
25225
Set Screw,
3x3mm
91560
5x10x4mm
Bearing
x1
25225
x1
42019
Wheel Hex
Pin, 2x11mm
x1
x1
42076
FT Wheel Hex,
6mm, Steel
42060
Lower 4-Link
Mount
x2
71032
2.5x14mm
SHCS
Front
Back
Right Left
