Associated Electrics RB10 - Tire Mounting and Body Preparation; Tire Bead Gluing Method

19
:: Electronics Build - Step 6
:: Tires and Body Build - Step 1
:: Electronics Build - Step 5
71023
Receiver Box
Plug and
Grommet
71026
Receiver
Box
25211
M3 x 10mm
BHCS
71026
Receiver
Box Lid
25211
M3 x 10mm
BHCS
x2
25225
M3 x 3mm
Set Screw
6338
Antenna
Tube & Cap
71050
Hook and
Loop Straps
x2
ESC
6727
Servo Tape
Battery
not included!
71197
Battery
Foam Spacer
Receiver
71023
Receiver
Box Seal
6727
Servo Tape
Build x2 (front and rear)
Clean the tire and wheel bead.
Carefully apply CA glue (tire ad-
hesive) to the tire bead on both
sides. Do one side at a time,
allow it to dry before
gluing the other side!
CA glue not included!
!
72019
Pre Glued
Wheel/Tire,
Rear
72018
Pre Glued
Wheel/Tire,
Front
#1597
ca glue
#1597
ca glue
