:: Table of Contents
:: Notes
1................... Cover
2................... Introduction
3...................1:1 Hardware “Fold Out”
4................... Table of Contents
5 - 7..............Quick Start Guide
8....................Front Top Plate and
Steering Build
9 - 10...........Front Suspension Build
10 - 11.........Rear Suspension Build
11 - 12........Gear Differential Build
12 - 13........Gearbox Build
13.................Slipper Build
13 - 14........Gearbox Install
14.................Rear Hub and CVA Build
15.................Turnbuckles Build
16 - 17.........Shocks Build
17 - 19........Electronics Build
19 - 20........Tires and Body Build
20 - 21....... Tuning Tips
22 - 29........Catalog
30................ Back Cover
4
There is a 1:1 hardware foldout page in the
front of the manual. To check the size of a part,
line up your hardare with the correct drawing
until you find the exact size. Each part in the
foldout has a number assigned to it for ordering
replacement parts.
This symbol indicates a special
note or instruction in the manual.
This symbol indicates a Racers Tip.
!
Associated Electrics, Inc.
21062 Bake Parkway.
Lake Forest, CA 92630
