Associated Electrics RC10 B6.4D TEAM KIT - Page 18

18
:: :: Bag 9 - Step 7Bag 9 - Step 7
:: :: Bag 9 - Step 8
33
22
BC A
11
Build x2 (right and left side)
25612
M3 Locknut
w/Flange
Build x2 (right and left side)
Use outside
hole in
front arm!
!
25188
M3 x 20mm
BHCS
x2x2
25612
M3 Locknut
w/Flange
Make sure the
flange on the
shock pivot ball is
towards the rear
arm.
!
33
44
22
BC
A
11
