Associated Electrics RC10 B7 TEAM KIT - Drivetrain and Rear Suspension Assembly; Bag 5: Gear Differential Assembly; Bag 4: Rear Arms and Spacers

10
:: :: Bag 4 -Bag 4 - Step 2 Step 2
:: :: Bag 5 -Bag 5 - Step 1 Step 1
:: :: Bag 5 -Bag 5 - Step 2 Step 2
!
The (#92432) C and (#92433) D aluminum
arm mounts allow for a large amount of setup
combinations when using the (#92014) 0.5°
and 1° arm mount inserts.
For a complete list of pill setup combinations,
please visit our website by using the link below.
http://bit.ly/B6PillChart
92496
Rear Hinge Pin
(Inner, 3.5x49.5mm)
92408
Rear Arm
Spacer
x4x4
x2x2
92138
Gear Diff
Outdrive Pin
92306
Gear Diff Sun
Gear LTC
92306
Gear Diff
washer
5x8.5x0.2mm
92133
Gear Diff
O-Ring, B74
92452
HD Gear Diff
Outdrive
92420
Gear Diff
Gear
x4x4
x4x4
92306
Planet Gear
Diff Shim
2.55x6.0x0.15mm
92306
Planet
Gear LTC
92307
Molded
Gears
LTC
92420
Gear Diff
Crosspin
91206
Gear Diff
washer
5x8.5x0.2mm
92133
Gear Diff
O-Ring, B74
92452
HD Gear Diff
Outdrive
92461
Gear Diff
Cover
BLACK GREASE
#6588
BLACK GREASE
#6588
Anti-SquatToe-In
1°
Kit Setup
1°
Kit Setup
Arm Mount C:
1° Out
Arm Mount D:
1° In
1
° Out
° Out
1
° In
