:: :: Bag 6 -Bag 6 - Step 3 Step 3
:: :: Bag 6 -Bag 6 - Step 4 Step 4
Diff Height
1
0
3
2
Kit
Setup
2
1
2
1
3
0
3
0
92295
Octalock Spur
Gear, 78T
48P
92448
B7 Top
Shaft Screw
x2x2
92287
Octalock
Slipper Pad,
11mm
92285
FT Octalock
LCF
Slipper Pad,
11mm
91803
B6.1 Slipper
Hub, Inner
92451
B7 Slipper Hub,
Outer
#92295 spur gear
walls should point
away from gear box.
There’s also a 72T, 48P
spur gear (#92293)
included for
stock motor use!
Add a drop of Diff Lube (#6591 -
not included) to the teeth of the diff
gear, idler gear, and top shaft.
25203
M3 x 12mm
FHCS
92427
B7 Spur
Gear Guard
92439
B7
Motor Mount
x3x3
92504
B7 Gearbox
Top
91048
Heavy-duty
Ballstud, 8mm
x2x2
x4x4
92440
B7 Rear
Ballstud Mount,
Aluminum
31383
Ballstud
Washers,
5.5x2.0mm,
Blue Aluminum
THREAD
LOCK
#1596
!
89204
M3 x 24mm
BHCS
x2x2
!
!
Diff Height Inserts:
The number on top
is the setting.
Stock diff height is 2.
Optional
rear bumper
included!
92407
B7 Diff
Height Insert
91563
10x15x4
Bearing
x2x2
x2x2
89203
M3 x 16mm
BHCS
31532
M3 x 8mm
BHCS
x4x4
92505
Carbon B7
Gearbox
Arm Mount D:
1° In
1
° In
91685
Rear
Bumper
92433
Aluminum
Arm Mount, D
92014
Arm Mount
Inserts (1°)
x2x2
FT DIFF LUBE
#6591
