Associated Electrics RC10B6.2D KIT - Bag 7 - Step 1; Bag 7 - Step 2; Bag 7 - Step 3

13
:: :: Bag 7 - Step 3
:: :: Bag Bag 7 - Step 27 - Step 2
:: :: Bag 7 - Step 1Bag 7 - Step 1
Build x2 (right and left side)
89202
M3 x 12mm
BHCS
x2x2
M3 x 12mm
91047
Heavy-duty
Ballstud,
6mm
92180
Rear Hub
Link Mounts
91857
B6.2 Rear
Hubs
92179
B6.2 Rear
Hub Inserts
31383
Ballstud Washers,
5.5x2.0mm, blue
x3x3
Rear Axle Height
1
0
3
2
+3mm
Kit
Setup
+2mm
+1mm
+0mm
0
3
1
2
1
2
0
3
#1596
thread lock
#1596
thread lock
Build x2 (right and left side)Build x2
#6588
black grease
91563
10 x 15 x 4
Bearing
91567
5 x 12 x 4
Bearing
91859
B6.2 CVA
Axle, +2mm
91438
CVA Pin
91438
CVA
Coupler
91434
CVA Bone,
67mm
Build x2 (right and left side)
91611
M1.6 x 5mm
SHCS
91436
CVA Wheel
Hex Pin
91610
Clamping Wheel
Hex, 7mm Offset
(rear)
Do not overtighten the
1.6 x 5mm SHCS into the
Clamping wheel hex.
!
Build x2 (right and left side)
92179
Rear Hub
Spacer
92188
Rear Hub
Hinge Pin
x2x2
25215
M3 Locknut
Hinge Pin will be tight in
the rear hub, but should
rotate freely
in the rear arms.
!
