Associated Electrics RC10B6.2D KIT - Bag 10 - Step 2; Bag 10 - Step 3; Bag 10 - Step 4

17
:: :: Bag 10 - Step 4Bag 10 - Step 4
:: :: Bag 10 - Step 3Bag 10 - Step 3
:: :: Bag 10 - Step 2Bag 10 - Step 2
Make sure the
battery strap
shoulder screw is
flush with the top of
your battery pack!
!
RRFF
flush with the top of
91730
Battery Strap
Shoulder
Screw
x2x2
ESC not
included!
6727
Servo
Tape
Antenna can be mounted
on the right or left side of
the chassis.
!
Receiver not
included!
25225
M3 x 3mm
Set Screw
6338
Antenna
Tube & Cap
11
22
33
44
55
FrontFront
31531
M3 x 6mm
BHCS
89218
3 x 8mm
Washer
x2
x2x2
x2x2
91731
Battery
Strap, B6
91731
B6 Battery
Strap Nut
31531
M3 x 6mm
BHCS
x2
x2
Battery
not included!
31530
M3 x 5mm
BHCS
x2x2
91729
Thumb
Screw, B6
x2x2
91866
B6.2 Wing,
front
91863
B6.2 Body,
clear
