Associated Electrics RC10B7D - Page 10

10
:: :: Bag 4 -Bag 4 - Step 2 Step 2
:: :: Bag 4 -Bag 4 - Step 3 Step 3
:: :: Bag 4 -Bag 4 - Step 4 Step 4
!
The (#92432) C and (#92433) D aluminum
arm mounts allow for a large amount of setup
combinations when using the (#92014) 0.5°
and 1° arm mount inserts.
For a complete list of pill setup combinations,
please visit our website by using the link below.
http://bit.ly/B6PillChart
92408
Rear Arm
Spacer
x4x4
!
!
!
8680
5 x 8 x 2.5mm,
Bearing
6581
3/32 Carbide
Diff Balls
91419
Diff Gear,
52T
92453
Ball Diff
Outdrive
HD Female
92453
Ball Diff
Outdrive
HD Male
7666
Diff Drive
Ring
7666
Diff Drive
Ring
x14x14
Build Tip:
The bottom side of the gear has 3 injection
dots. This side faced down will keep the diff
balls from falling thru the holes
Build Tip:
Install the fi rst washer (grove up), add
grease #6588. Install the caged thrust
washer.
Add grease on top of the balls, then install
the 2nd washer (grooves down).
Build Tip:
Do this entire step with the diff screw
on the end of your wrench for better
control.
8680
5 x 8 x 2.5mm,
Bearing
FT DIFF LUBE
#6591
FT DIFF LUBE
#6591
FT DIFF LUBE
#6591
92496
Rear Hinge Pin
(Inner, 3.5x49.5mm)
x2x2
Anti-SquatToe-In
3°
Kit Setup
2°
Kit Setup
Arm Mount C:
1° In
Arm Mount D:
1° In
1
° In
1
° In
5 x 8 x 2.5mm,
Do this entire step with the diff screw
on the end of your wrench for better
Install the fi rst washer (grove up), add
grease #6588. Install the caged thrust
Add grease on top of the balls, then install
5 x 8 x 2.5mm,
BLACK GREASE
#6588
91990
Thrust
Washer
91990
Caged Thrust
Bearing
6573
Diff Thrust
Bolt
x2x2
