:: :: Bag 6 -Bag 6 - Step 3 Step 3
:: :: Bag 6 -Bag 6 - Step 4 Step 4
!
Diff Height
1
Kit
Setup
0
3
2
2
1
2
1
3
0
3
0
92295
Octalock Spur
Gear, 78T
48P
91803
B6.1 Slipper
Hub, Inner
#92295 spur gear
walls should point
away from gear box.
Diff Height Inserts:
The number on top
is the setting.
Stock diff height is 1.
Add a drop of Diff Lube (#6591 -
not included) to the teeth of the diff
gear, idler gear, and top shaft.
91563
10x15x4
Bearing
x2x2
25203
M3 x 12mm
FHCS
x3x3
91048
Heavy-duty
Ballstud, 8mm
x2x2
x2x2
92440
B7 Rear
Ballstud Mount,
Aluminum
31383
Ballstud
Washers,
5.5x2.0mm,
Blue Aluminum
THREAD
LOCK
#1596
!
92451
B7 Slipper Hub,
Outer
92427
B7 Spur
Gear Guard
92439
B7
Motor Mount
92407
B7 Diff
Height Insert
x2x2
Arm Mount D:
1° In
1
° In
31532
M3 x 8mm
BHCS
89204
M3 x 24mm
BHCS
x2x2
89203
M3 x 16mm
BHCS
x4x4
91685
Rear
Bumper
92433
Aluminum
Arm Mount, D
92014
Arm Mount
Inserts (1°)
x2x2
92504
B7 Gearbox
Top
92505
Carbon
B7 Gearbox
!
Optional
rear bumper
included!
92448
B7 Top
Shaft Screw
x2x2
92288
Octalock
Slipper Pad,
19mm
92286
FT Octalock
LCF
Slipper Pad,
19mm
There’s also a 72T, 48P
spur gear (#92293)
included for
stock motor use!
FT DIFF LUBE
#6591
