Associated Electrics RC8.2e - Front Suspension Assembly (Bag E & EE)

:: Front Bulkhead Assembly (cont.) - Bag D & DD
:: Front Suspension Assembly - Bag E & EE
:: Front Suspension Assembly (cont.) - Bag E & EE
3
2
1
11
Build right
and left sides!
Right Side
Left Side
Build right
and left
sides!
Build Two!
!
!
!
89162
15x21x4mm
bearing
89223
3x8mm
shcs
89095
Wheel hex
(aluminum)
89096
Wheel hex
pins
89380
FT machined
steering blocks
89473
Steel
shock
standoffs
89285
Front stub
axle
(aluminum)
25236
8x16x5mm
bearing
89230
Silver
cone
washer
89225
3x24mm
shcs
89105
CVA
u-joint
coupler
89102
CVA
bone
89105
CVA pin
x2
x2
x2
#1596
thread lock
#1596
thread lock
#6588
black grease
#6588
black grease
#1596
thread lock
Axle has additional holes
for crosspin to extend
the life of the Axle.
!
!
