Associated Electrics RC8B4.1 - Page 12

12
:: :: Front Gearbox Front Gearbox BuildBuild - Bag - Bag 5.1, 5.2, 5.35.1, 5.2, 5.3 -- Step 4Step 4
:: :: Front Gearbox Front Gearbox BuildBuild - Bag 5.1, 5.2, 5.35.1, 5.2, 5.3 -- Step 5
:: :: Front Gearbox Front Gearbox BuildBuild - Bag - Bag 5.1, 5.2, 5.35.1, 5.2, 5.3 -- Step 3Step 3
Center the anti-roll
bar collet on the anti-
roll bar, then tighten
the 3x3mm set
screw.
Front anti-roll
bar gap: 2.0mm
!
!
25225
3x3mm
Set Screw
81585
Anti-Roll
Bar
Collet
81129
(Front) Anti-Roll
Bar, 2.2mm
81260
M4x14mm
BHCS
x2x2
81520
Arm Mount
Insert, Center
81520
Arm Mount
Insert, Center
81567
Arm Mount
B
x2x2
x2x2
Kit Setup:
81585
Anti-Roll
Bar Pivot
81512
Anti-Roll
Bar Link
81562
Rod End
Ball
x2x2
Build left and right side!
Note direction
Center!
Note direction
Start here,
adjust to
101mm
shock length.
!
!
!
!
81260
M4x14mm
BHCS
x2x2
x2x2
x2x2
81566
Arm Mount
A
81641
Hinge
Pin
81446
Suspension
Arm Shim
81636
Front Lower
Arm, Soft
89203
M3x16mm
BHCS
x2x2
89317
Droop
Screw
Droop Screw:
Kit Setup:
1.5mm
