Associated Electrics RC8B4.1 - Linkages Build; Throttle and Brake Linkage Build

:: Linkages Build - - Bag 10.1 - Step 1- Step 1
21
:: Linkages Build:: Linkages Build - - Bag 10.1 Bag 10.1 - Step 2- Step 2
:: C:: Center Bulkheadenter Bulkhead - - Bag 9.1 Bag 9.1 - Step 4- Step 4
Install Brake Links so they
are flush with the back of
the servo horn pivots.
!
18.40mm
(0.72”)
Install Brake Links so they
are flush with the back of
!
Recommended Starting Positions:
Front Brake Gap
7.75mm
Rear Brake Gap
4.5mm
Note direction of
center diff.
!
89212
M3x30mm
FHCS
x4x4
81550
Brake
Rotor
81580
Center
Dog Bone,
93.5mm
81581
Center
Dog Bone,
104mm
23T
25T
Spline Count
Printed here
#1596
thread lock
x3x3
x2x2
x4x4
81555
Brake Bias
Collar
81555
Brake
Link
81555
Throttle
Link
81555
Throttle
Spring
81555
Throttle
Ball Cup
81555
Set Collar
25225
M3x3mm
Set Screw
x3x3
x3x3
81556
Servo Horn
Insert
7184
M2x16mm
SHCS
81251
M2x10mm
SHCS
81555
Pivot
Bushing,
Throttle
81251
Washer
81555
Servo
Horn Pivot
81555
Pivot
Bushing,
Brake
81556
Servo Horn,
Throttle
25225
M3x3mm
Set Screw
x2x2
81555
Set Collar
81555
Brake Linkage
Spring Ball
81555
Brake
Spring
x2x2
x2x2
x2x2
#1596
thread lock
