Associated Electrics Rival MT10 - Step 1 Assembly

:: Step 3
:: Step 2
6
:: Step 1
25810
Sun Gear
Shim
25810
Sun Gear
Shim
25810
Sun Gear
25810
Diff
O-Ring
25810
Diff
O-Ring
25810
Input Pin
25810
Sun Gear
25810
Input Pin
31350
2.5x10mm
FHCS
91563
10x15x4mm
Bearing
25808
Diff Gasket
25812
Sun Gear
Shim
25812
Sun Gear
Shim
25812
Input Pin
25812
Input Pin
25812
Center Diff
Sun Gear
25812
Center Diff
Sun Gear
25811
Spur Gear
(54T, 32P)
25807
Diff Case
(Center)
25812
Diff
O-Ring
25812
Center Diff
Shaft
25812
Center Diff
Outdrive
91564
8x16x5mm
Bearing
25810
Planetary
Gear
25810
Diff Cross
Pin
25810
Diff Output
Shaft
25810
Diff Output
Shaft
25807
Diff Case
(Front/Rear)
25808
Ring Gear,
37T
x4
x2
x2
x4
x4
25810
Planetary
Gear Shim
25812
Diff O-Ring
diff
fluid
Front Diff Fluid:
60k cst #5458
Rear Diff Fluid:
3k cst #5452
Build 2 (1 front, 1 rear)
Build 1 (1 center)
