Appendix A:

DATA

Comments

Status code

'0000' : No error

'0001' : Signal is lower than sensor sensitivity

'0002' : Out of range due to T brightness minimum

'0003' : Too low energy

'0004' : Signal is higher than sensor sensitivity

'0006' : Sharp brightness jump

'0007' : Non stable object measurement

'0011' : Internal temperature warning

'0013' : Thermopile ambient temperature too low

'0014' : Thermopile ambient temperature too high

'0015' : Pyrometer in testing mode

'0016' : Pilot light ON

0017 : Measurement below lower basic range

0018 : Measurement exceeds upper basic range

0019 : Pyrometer in warm up period

' '

Broadcast Message:

WD (Batch Write) command with Station ID of 0 is considered as broadcast message. Sensors process this command

regardless of their Station Number and do not issue replies.

It is useful when master issues a request to change the same parameters of more than one Slave devices.

For more information write us at, technical@accuratesensors.com
