Maintenance and Technical Data
6.9
Engine Oil Level
Warning: Engine oil or components may be hot and could
cause severe burns.
Caution: Running the engine with engine oil below the
lower mark or above the upper mark can cause serious
engine damage.
Caution: This vehicle's warranty may be invalidated if
damage is caused by the use of incorrect engine oil. Low
quality or obsolete oils do NOT give the protection required
by modern, high performance engines.
Caution: Failure to use engine oil that meets the required
specification can cause excessive engine wear, a build up of
sludge and deposits, and increased pollution. It could also
lead to engine failure.
Caution: Care must be taken when oil is checked or
added. If oil drips onto any of the engine hoses, this can cause
them to swell and become damaged over time.
Engine Oil Level Check
1. Make sure the vehicle is on level ground.
2. Run the engine until the oil temperature is 75°C or higher.
Engine oil temperature can be checked in the infotainment
system (Refer to ’Vehicle Menu’, page 4.13).
3. Once the oil temperature is at least 75°C, increase the
engine speed to 3000 rpm and hold for 30 seconds.
4. Turn the engine off.
For the oil level check process, the oil temperature must be
between 75°C and 85°C
5. Between 10 and 20 seconds after the engine is turned off,
unscrew the oil filler cap. Withdraw and wipe the dipstick
with a clean lint free cloth.
6. Fully insert the dipstick into the oil tank, and withdraw the
dipstick again.
7. The engine oil level should read between the Min. (A) and
Max. (B) indentation marks.
