Aston Martin VALKYRIE 2021 - Electrical Systems; Fuse Box (A); Fuse Box (B); Fuse Box (C)

6.20 Maintenance and Technical Data
Fuse Box (A)
Fuse Box (B)
Fuse Box (C)
Fuse Box (D)
Fuse Box (E)
Fuse Box (F)
F1 5A Secondary Air Valves
F2 4A Water Run-on Pump
F3 3A Engine Management System (EMS) Master Relay
F4 20A EMS Master Relay
F5 5A DMTL
Purge Valve
F6 3A Tyre Pressure monitoring System (TPMS)
F7 3A EMS Slave Relay
F8 20A EMS Slave Relay
F1 5A Bank B VVT Solenoids
F2 7.5A Bank B Fuel Injectors
F3 5A Bank A VVT Solenoids
F4 7.5A Bank A Fuel Injectors
F5 7.5A Bank B Lambda Sensor
F6 10A Bank B Ignition Coils
F7 7.5A Bank A Lambda Sensor
F8 10A Bank A Ignition Coils
F1 7.5A Right Side Exhaust Bypass
F2 7.5A Left Side Exhaust Bypass
F3 - Not Used
F4 3A Left Side Radiator Fan
F5 3A Right Side Radiator Fan
F6 - Not Used
F7 - Not Used
F8 - Not Used
F1 30A Left Electric park Brake (EPB) Supply
F2 15A Direct Drive Valve (DDV) - Suspension
F3 30A Transmission ECU
F4 3A Cabin Accelerometers
F5 30A Right EPB Supply
F6 7.5A Left Side DDV - Gearbox
F7 30A ACU Module
F8 7.5A Left Side DDV -Aero
F1 40A Right Side Radiator Fan
F2 30A Charge Port
F3 40A Left Side Radiator Fan
F1 50A Left Side Secondary Air Pump
F2 50A Right Side Secondary Air Pump
