INST 318 HINRG HEATER – V01-18
- 10 -
4
PRE BEND THE FLUE WHERE REQUIRED.
BENDS ARE MADE BY CURVING THE FLUE
PIPE AROUND A GENTLE RADIUS SUCH AS
A PIPE OR KNEE. DO NOT OVER BEND
AND KINK FLUE PIPE. KEEP BENDS TO A
MINIMUM AND USE AS LARGE AS RADIUS
AS POSSIBLE. MINIMUM INTERNAL
RADIUS IS 250MM.
BENDS CAN BE STRAIGHTENED IF
REQUIRED.
5
TAKE THE FLUE COVER INDOOR INSERT.
6
TAKE THE FLUE AND FEED IT THROUGH
THE INDOOR INSERT.
7
FIT FLUE PIPE TO APPLIANCE (NON-
SLEEVED END OF FLUE). FIT BY SLIDING IT
OVER THE FLUE CONNECTION SPIGOT AS
FAR AS POSSIBLE.
