ENGLISH ____________________________________________________________________
IMPORTANT: The instruction manual you are holding includes essential information on the safety measures to be implemented for
installation and start-up. Therefore, the installer as well as the user must read the instructions before beginning installation and start-up.
Keep this manual for future reference.
Disposal of waste electrical and electronic domestic systems in the European Union.
All the products marked with this symbol indicates that the product shall not be mixed or disposed with your
household waste at their end of use. It is responsibility of the user to eliminate this kind of wastes depositing them in
a recycling point adapted for the selective disposal of electrical and electronic wastes. The suitable recycling and
treatment of these wastes contributes in essential way to the preservation of the Environment and the health of the
users. For further information regarding the points of collection of this type of wastes, please contact to the dealer
where you acquired the product or to your municipal authority.
For optimum performance of the Astralpool Chlore Salt Electrolysis System, we recommend you to follow the instructions given below:
1. CHECK THE CONTENTS OF THE PACK: ______________________________________________________________________________
You should find the following elements inside the box:
• Power supply
• Electrolysis cell
• Flow detector
• Saddle 50 mm – ½”
• Operation Manual
2. GENERAL FEATURES: _____________________________________________________________________________________________
When Astralpool Chlore Salt Electrolysis System is installed, a quantity of salt is dissolved into the swimming pool water. This salty water then
passes through the electrolysis cell that is located in the plant room. The Astralpool Chlore Salt Electrolysis System consists of two elements:
an electrolysis cell and a power supply. The electrolysis cell contains a quantity of titanium plates (electrodes).
When a weak electrical current is passed through the plates inside the electrolysis cell, chlorine is produced. Maintaining a level of chlorine in
swimming pool water keeps the water sanitised and healthy to swim in. The Astralpool Chlore Salt Electrolysis System will manufacture chlorine
whenever the pool circulation system (pump and filter) is operational.
The power supply is provided with various safety devices, which are activated in case of irregular operation of the system, as well as a
microprocessor driven control system.
The Astralpool Chlore Salt Electrolysis Systems have an automatic cleaning system that avoids scale formation on the electrodes.
MODEL
DESCRIPTION
SMART+ 60 – Code 42350 SMART+ 100 – Code 42351 SMART+ 160 – Code 42352
Standard working voltage 230 V AC, 50 Hz.
Output (dc) 12 A 24 A 32 A
Production (g/h) 10 - 12 20 -24 25 - 32
Flow detector Gas detector + flow switch
Salinity range / Temperature 4 – 6 g./l. / +15
o
C – 40
o
C (59
o
F – 104
o
F)
Electrodes
SELF-CLEANING coated Titanium
Estimated lifetime: 4.000 – 7.000 hours of operation (depending on water quality)
Production control 0 – 100 % ( 11 production levels)
Cover control
Input for potential free contact
Programmable reduction of production from control panel when closed cover [10 ... 90%]
Polarity switch Programmable from control panel: 2/3 hours + test mode
External control
Two inputs for potential-free contacts for external flow detector and ORP/RESIDUAL CHLORINE
controller
Programmable contact logics from unit control panel
Salt level protection Automatic production protection
