5. CABLE AND CABLE GLAND ASSEMBLY:
6. MAINTENANCE:
This product does not require any maintenance. If you become aware that it is not working properly, please
contact our customer service department.
7. CONTROL SYSTEMS:
The monochrome models do not need a control system. The can be turned on and off using an external
switch.
The RGB models have two operating modes depending on the type of control system purchased:
• 12 colors, 8 sequences and 8 sequence change speeds. Controllers: LumiPlus Top (27818
+ 41988), LumiPlus WiFi Access Point (59132) or LumiPlus ModBUS (57435). See the corresponding manual.
• 7 colors and 7 sequences. LumiPlus Eco Controller (32458). See the corresponding manual.
Max. cable
2x1,5mm
!
The length of cable
stripped is very important
to keep the product
watertight.
7mm
17mm
Max.6Nm
6Nm
