16
5.3. Production level selection
To select the desired production level, press the “
-” [1] / “+” [14] keys until the production level light blinks. The system information screen
[11] will display the value of the production scale light [4]. The system will set its production to the desired level after a few seconds.
Fig. 22
In normal conditions, the production value [4] should be the same as the programmed value. If the salt level in the water is outside the
permitted range (“HIGH SALT” [7] or “LOW SALT” [6] alarms on), or there is a problem in the electrolysis cell (“ELECTRODES” [13] alarm
on), however, the production value [4] could be lower than the programmed and displayed value [11].
WINTER Mode: during periods of low water temperature, where the chlorine demand will be low, select a production level [1] of 50-
60%, because in this way power consumption and lifetime of the package of electrodes are optimized.
5.4. Salinity test
AstralPool Chlore Smart + systems have an integrated system to detect the salinity level of pool water. To run the test, press the “SALT
TEST” [9] key. During the test, the production light will range from 20%-80% of the salinity scale [5], alternately displaying “SALT” and “TEST”
on the system information screen [11]. Once the test is completed, the light will blink for a few seconds on the scale [5] on the detected
salinity value (see Fig. 23). The equipment will return to normal operating mode after a few seconds.
Fig. 23
The system might show lower than actual salt levels if the temperature falls beneath 20
O
C.
